Part No

90NB14X1-M009L0

Sales Model Name

UX8406CA-OLED009WS

EAN Code

4711387813539

UPC Code

197105813533

WEEE

1.11

BASE UNIT

VSNB14X1-BU1000

Marketing Name

ASUS Zenbook Duo

Operating System

Windows 11 Home - ASUS recommends Windows 11 Pro for business

Office

Microsoft 365 Personal 1-year included

LCD cover-material

Mg-Al

LCD cover-color

Inkwell Gray

Top case-material

Mg-Al

Top case-color

Inkwell Gray

Keyboard color

Black

Bottom case-material

Mg-Al

Bottom case-color

Inkwell Gray

Military grade

US MIL-STD 810H military-grade standard

Touch Panel

Touch screen

Panel Size

14.0-inch

Resolution

3K (2880 x 1800) OLED 16:10 aspect ratio

Response time

0.2ms response time

Refresh rate

120Hz refresh rate

Brightness

400nits

Peak Brightness

500nits HDR peak brightness

Color gamut

100% DCI-P3 color gamut

Gamut mapping

Yes

Contrast ratio

1,000,000:1

VESA CERTIFIED Display HDR

VESA CERTIFIED Display HDR True Black 500

Color depth

1.07 billion colors

Pantone

PANTONE Validated

Glare

Glossy display

Low blue light

70% less harmful blue light

Screen-to-body ratio

91%

Stylus support

With stylus support

Processor

Intel Core Ultra 9 Processor 285H 2.9 GHz (24MB Cache, up to 5.4 GHz, 16 cores, 16 Threads); Intel AI Boost NPU up to 13TOPS

Chipset

N/A

Discrete/Share

Share

Intergrated GPU

Intel Arc Graphics

Neural Processor

Intel AI Boost NPU up to 13TOPS

Expansion Slot(includes used)

1x M.2 2280 PCIe 4.0x4

On board memory

32GB LPDDR5X on board

Total System Memory

LPDDR5X 32GB

Storage

2TB M.2 NVMe PCIe 4.0 SSD

Front-facing camera

FHD camera with IR function to support Windows Hello

on board Wireless

Wi-Fi 7(802.11be) (Tri-band)2*2 Bluetooth 5.4 Wireless Card (*Bluetooth version may change with OS version different.)

Keyboard type

Soft Keyboard

Touchpad

Precision touchpad

FingerPrint

N/A

I/O ports

1x USB 3.2 Gen 1 Type-A (data speed up to 5Gbps)

2x Thunderbolt 4 with support for display / power delivery (data speed up to 40Gbps)

1x HDMI 2.1 TMDS

1x 3.5mm Combo Audio Jack

Audio

Smart Amp Technology

Built-in speaker

Built-in array microphone

Voice control

with Cortana support

Power

TYPE-C, 65W AC Ultra Mini Adapter, Output: 20V DC, 3.25A, 65W, Input: 100-240V AC 50/60GHz universal, TYPE-C Cable: 240W

Required charging power

Min: 45W

Max: 65W

*The indicated wattage is for demonstrating the systems support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Battery

75WHrs, 4S1P, 4-cell Li-ion

Replaceable Battery

No

Dimension (W x H x D)

31.35 x 21.79 x 1.46 ~ 1.99 cm (12.34" x 8.58" x 0.57" ~ 0.78")

Dimension for Keyboard

31.28 x 20.90 x 0.51 ~ 0.53 cm (12.31" x 8.23" x 0.20" ~ 0.21")

Weight (with Battery)

1.65 kg (3.64 lbs)

Weight of system: 1.35 kg

Weight of keyboard: 0.30 kg

Weight (without Battery)

1.39 kg (3.06 lbs)

Antivirus

N/A

Security

IR webcam with Windows Hello support

Trusted Platform Module (Firmware TPM)

MyASUS feature

System diagnosis

Battery health charging

Fan Profile

Splendid

Tru2Life

Function key lock

WiFi SmartConnect

TaskFirst

Live update

ASUS OLED Care

AI Noise Canceling

Built-in Apps

ASUS Recovery

CapCut

MyASUS

ScreenXpert

GlideX

Adobe Creative Cloud Hard Bundle

One-Month Membership of Adobe Creative Cloud All Apps, Individual.

The redemption duration from September 15, 2021 to August 31, 2025.

Included in the Box

Stylus (ASUS Pen SA203H-MPP2.0 support)

Backpack

Sleeve

Ecolabels & Compliances

EPEAT Gold

Energy star 8.0

RoHS

Reparability Index (for France)

9.4
