Garmin ECHOMAP Ultra 126sv Boat Navigator, Sonnar, Transducer
The sunlight-readable 12 touchscreen combo features preloaded coastal and inland Garmin Navionics mapping, plus the transducer bundle adds CHIRP traditional and Ultra High-Definition scanning sonars.
- The keyed-assist 12 touchscreen puts fishfinding know-how at your fingertips.
- See crisp images of structure and fish in stunning detail.
- Navigate confidently with built-in Garmin Navionics inland and coastal mapping.
- Manage your marine experience from nearly anywhere with the ActiveCaptainapp1.
- Connect your boat to share data, sonar and charts with your other compatible devices.
- Explore your new favorite spot; create maps on the fly, and tailor them to fit your needs.
LIVESCOPESONAR SUPPORT
ECHOMAP Ultra supports a variety of Garmin transducers (sold separately), including LiveScope all-seeing live sonar.
BUILT-IN UHD SONAR
Built-in UHD sonar provides Garmin CHIRP traditional sonar plus Ultra High-Definition ClearV and SideV scanning sonars when paired with a compatible UHD transducer. Transducer bundled products include thetransducers with three scanning sonar frequencies and 20% greater range for your UHD SideV sonar.
VIVID COLOR PALETTES
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
ADD CHARTS
Experience unparalleled coverage and detail with optional Garmin Navionics integrated mapping or optional Garmin Navionics Vision premium mapping with high-resolution relief shading, satellite imagery, sonar imagery and more. They even come with a 1-year subscription for downloadable daily updates.
QUICKDRAW CONTOURS
Create personalized fishing maps on-screen with 1 contours. Keep the data to yourself, or share it with the Garminon the2.
NETWORK CAPABLE
If you have multiple compatible ECHOMAP Ultra 10 or 12 units or ECHOMAP Plus or UHD 7 and 9 units on your boat, you can share information such as sonar, user data and charts among them.
NMEA 2000NETWORK COMPATIBILITY
Connect to your compatible autopilots, digital switching, weather, Fusion-Linkaudio system, media, VHF, AIS, engine data, heading sensors such as the SteadyCastsensor and more from one screen.
ACTIVECAPTAIN APP
Built-in Wi-Ficonnectivity pairs with the free all-in-onefor access to the OneChartfeature, smart notifications, software updates, Garmin Quickdraw Community data and more1.
FORCE TROLLING MOTOR COMPATIBILITY
Take control of the most powerful and efficientavailable3, route it to waypoints, follow tracks and more from the screen of your chartplotter.
TAKE IT WITH YOU
Keep your ECHOMAP Ultra safe and secure. Cords plug directly into the quick-disconnect bail mount, which allows you to quickly install and remove your unit.
What's in the box
- ECHOMAP Ultra with worldwide basemap
- GT56UHD-TM transducer (if option is selected
- Power/data cable
- Tilt mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
Specifications
General | |
| DIMENSION | 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm) |
|---|---|
| TOUCHSCREEN | |
| INPUT | Touchscreen with Keyed Assist |
| DISPLAY SIZE | 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal) |
| DISPLAY RESOLUTION | 1280 x 800 pixels |
| DISPLAY TYPE | WXGA, IPS |
| WEIGHT | 5.5 lbs (2.5 kg) |
IPX7 | |
| MOUNTING OPTIONS | Bail or flush |
Maps & Memory | |
| ACCEPTS DATA CARDS | 2 microSDcards |
|---|---|
| WAYPOINTS | 5000 |
| TRACK POINTS | 50,000 |
| TRACKS | 50 saved tracks |
| NAVIGATION ROUTES | 100 |
Sensors | |
| HAS BUILT-IN RECEIVER | |
|---|---|
| RECEIVER | 10 Hz |
| NMEA 2000 COMPATIBLE | |
| NMEA 0183 COMPATIBLE | |
| GPS | |
| SUPPORTS WAAS | |
Built-in Maps | |
| TIDE TABLES | |
|---|---|
Optional Map Support | |
| GARMIN NAVIONICS | |
|---|---|
| GARMIN NAVIONICS VISION | |
| TOPO | |
| STANDARD MAPPING | |
| GARMIN QUICKDRAW CONTOURS | |
Chartplotter Features | |
| AIS | |
|---|---|
| DSC | |
| SUPPORTS FUSION-LINK COMPATIBLE RADIOS | |
| ACTIVECAPTAIN COMPATIBLE | yes |
| SAILING FEATURES | |
Sonar Features & Specifications | |
| DISPLAYS SONAR | |
|---|---|
| POWER OUTPUT | 600 W |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) |
| CLEARV | built-in 260/455/800/1000/1200 kHz |
| SIDEV | built-in 260/455/800/1000/1200 kHz |
| PANOPTIX SONAR | |
| LIVESCOPE | |
Connections | |
| NMEA 2000 PORTS | 1 |
|---|---|
| CONNECTIONS NMEA0183 INPUT PORTS | 1 |
| NMEA 0183 INPUT (TX) PORTS | 1 |
| GARMIN MARINE NETWORK PORTS | 2 (large connector) |
| 12-PIN TRANSDUCER PORTS | 1 LVS sonar; 1 scanning sonar |
Electrical Features | |
| POWER INPUT | 9 to 18 Vdc |
|---|---|
| TYPICAL CURRENT DRAW AT 12 VDC | 3.0 A |
| MAXIMUM CURRENT DRAW AT 12 VDC | 3.3 A |
| MAXIMUM POWER USAGE AT 10 VDC | 26.2W |
