Processor | Intel Core i5-1235U, 10C (2P 8E) / 12T, P-core 1.3 / 4.4GHz, E-core 0.9 / 3.3GHz, 12MB |
Graphics | NVIDIA GeForce MX550 2GB GDDR6 |
Chipset | Intel SoC Platform |
Memory | 16GB Soldered DDR4-3200 |
Memory Slots | Memory soldered to systemboard, no slots, dual-channel (Intel i5 / i7 models) |
Max Memory | 16GB soldered memory, not upgradable |
Storage | 512GB SSD M.2 2242 PCIe 4.0x4 NVMe |
Storage Support | Models with 57Wh battery: up to two drives, 1x 2.5" HDD 1x M.2 SSD 2.5" HDD up to 1TB M.2 2242 SSD up to 512GB M.2 2280 SSD up to 1TB |
Storage Slot | Models with 57Wh battery: one 2.5" drive slot one M.2 slot One 2.5" SATA HDD slot One M.2 2280 PCIe 4.0 x4 slot |
Card Reader | SD Card Reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, Realtek ALC3287 codec |
Speakers | Stereo speakers, 2W x2, optimized with Dolby Audio |
Camera | FHD 1080p with Privacy Shutter |
Microphone | 2x, Array |
Battery | Integrated 57Wh |
Power Adapter | 65W USB-C (3-pin) |
DESIGN |
Display | 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 45% NTSC |
Touchscreen | None |
Keyboard | Backlit, English (UK) |
Case Color | Storm Grey |
Surface Treatment | Aluminium Stamping (Anodized) |
Case Material | Aluminium (Top), PC-ABS (Bottom) |
Dimensions (WxDxH) | 356.67 x 233.13 x 17.9 mm (14.04 x 9.18 x 0.70 inches) |
Weight | Starting at 1.77 kg (3.90 lbs) |
SOFTWARE |
Operating System | None |
Bundled Software | None |
CONNECTIVITY |
Ethernet | No Onboard Ethernet |
WLAN Bluetooth | Wi-Fi 6, 11ax 2x2 BT5.2 |
Standard Ports | - 1x USB 3.2 Gen 1
- 1x USB 3.2 Gen 1 (Always On)
- 2x USB-C 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort 1.2)
- 1x HDMI 1.4b
- 1x Headphone / microphone combo jack (3.5mm)
- 1x SD card reader
|
Docking | Various docking solutions are supported via USB-C. |
SECURITY & PRIVACY |
Security Chip | Firmware TPM 2.0 |
Fingerprint Reader | Touch Style, Integrated in Power Button |
Other Security | Camera privacy shutter |
SERVICE |
Base Warranty | 1-year, Courier or Carry-in |
Included Upgrade | None |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | |
Mil-Spec Test | MIL-STD-810H military test passed |
