Name: Lenovo V14 Laptop, AMD Ryzen 3 3250U, 14 Inches FHD, 1TB HDD, 4GB RAM, AMD Radeon Graphics, DOS - Grey 82C600DJAX
SKU: 685688

Lenovo V14 Laptop, AMD Ryzen 3 3250U, 14 Inches FHD, 1TB HDD, 4GB RAM, AMD Radeon Graphics, DOS - Grey 82C600DJAX

Processor	AMD Ryzen 3 3250U (2C / 4T, 2.6 / 3.5GHz, 1MB L2 / 4MB L3)
Graphics	Integrated AMD Radeon Graphics
Chipset	AMD SoC Platform
Memory	4GB Soldered DDR4-2400
Memory Slots	One memory soldered to systemboard, one DDR4 SO-DIMM slot
Max Memory	Up to 12GB (4GB soldered 8GB SO-DIMM) DDR4-2400
Storage	1TB HDD 5400rpm 2.5"
Storage Support	Up to two drives, 1x 2.5" HDD 1x M.2 SSD 2.5" HDD up to 1TB M.2 2242 SSD up to 512GB M.2 2280 SSD up to 512GB
Card Reader	4-in-1 Card Reader
Optical	None
Audio Chip	High Definition (HD) Audio
Speakers	Stereo speakers, 1.5W x2, Dolby Audio
Camera	0.3MP
Microphone	Mono
Battery	Integrated 35Wh
Max Battery Life	MobileMark 2014: 6 hr (35Wh)
Power Adapter	65W Round Tip (2-pin, Wall-mount)
DESIGN
Display	14" FHD (1920x1080) TN 220nits Anti-glare
Touchscreen	None
Keyboard	Non-backlit, Arabic
Case Color	Iron Grey
Surface Treatment	Texture
Case Material	PC ABS
Dimensions (WxDxH)	327.1 x 241 x 19.9 mm (12.88 x 9.49 x 0.78 inches)
Weight	Starting at 1.6 kg (3.53 lbs)
SOFTWARE
Operating System	FreeDOS
Bundled Software	None
CONNECTIVITY
Ethernet	None
WLAN Bluetooth	11ac, 2x2 BT5.0
Standard Ports	1x USB 2.0 2x USB 3.1 Gen 1 1x HDMI 1.4b 1x Card reader 1x Headphone / microphone combo jack (3.5mm) 1x Power connector
SECURITY & PRIVACY
Security Chip	Firmware TPM 2.0
Fingerprint Reader	None
SERVICE

Included Upgrade	None
CERTIFICATIONS
Green Certifications	ErP Lot 3 RoHS compliant

1. Power connector

5. Power indicator

2. HDMI 1.4b

6. NOVO button hole

3. USB 2.0

7. Headphone / microphone combo jack (3.5mm)

4. 2x USB 3.1 Gen 1

8. Card reader

Processor Family

AMD 3000, AMD Athlon, or AMD Ryzen 3 Processor

Processor

AMD Ryzen 3 3250U

2

4 2.6GHz

3.5GHz

1MB L2 / 4MB L3

DDR4-2400

AMD Radeon Graphics

Operating System

FreeDOS

Graphics	Type	Memory	Key Features
AMD Radeon Graphics	Integrated	Shared	DirectX 12

Monitor Support

Supports up to 2 independent displays (native display and 1 external monitor via HDMI) HDMI supports up to 3840x2160 30Hz

Chipset

AMD SoC (System on Chip) platform

Max Memory

Up to 8GB (8GB SO-DIMM) DDR4-2400
Up to 12GB (4GB soldered 8GB SO-DIMM) DDR4-2400

Memory Slots

One DDR4 SO-DIMM slot
One memory soldered to systemboard, one DDR4 SO-DIMM slot

Memory Type

DDR4-2400

Storage Support

Up to two drives, 1x 2.5" HDD 1x M.2 SSD 2.5" HDD up to 1TB M.2 2242 SSD up to 512GB M.2 2280 SSD up to 512GB

Storage Type

Disk Type	Interface	RPM	Security
2.5" SATA HDD	SATA 6Gb/s	5.4K	-
M.2 2242 SSD	PCIe NVMe, PCIe 3.0 x2	-	-
M.2 2280 SSD	PCIe NVMe, PCIe 3.0 x4	-	-

Removable Storage

Optical

None

Card Reader

4-in-1 card reader (SD, SDHC, SDXC, MMC)

Multi-Media

Audio Chip

High Definition (HD) Audio

Speakers

Stereo speakers, 1.5W x2, Dolby Audio

Microphone

Single microphone

Camera

0.3-megapixel, fixed focus

Battery

Integrated Li-Polymer 30Wh battery
Integrated Li-Polymer 35Wh battery

Max Battery Life^[1]

MobileMark 2014: 5 hr (30Wh)
MobileMark 2014: 6 hr (35Wh)

Power Adapter

65W round tip (2-pin, wall-mount) AC adapter, 100-240V, 50-60Hz

Design

Display

14.0"

FHD (1920x1080)

None

TN

220 nits

Anti-glare

16:9

-

Touchscreen

Non-touch

Input Device

Keyboard

6-row, spill-resistant, multimedia Fn keys

Keyboard Backlight

Non-backlight

Touchpad

Buttonless Mylar surface multi-touch touchpad

Mechanical^[1]

Dimensions (WxDxH)

327.1 x 241 x 19.9 mm (12.88 x 9.49 x 0.78 inches)

Weight

Starting at 1.6 kg (3.53 lbs)

Case Color

Iron grey

Surface Treatment

IMR (in-mold decoration by roller)
Texture

Case Material

PC ABS (top), PC ABS (bottom)

Connectivity

Network

Onboard Ethernet

No Ethernet

WLAN Bluetooth

802.11ac 2x2 Wi-Fi Bluetooth 5.0, M.2 card

Ports

Standard Ports

1x USB 2.0
2x USB 3.1 Gen 1
1x HDMI 1.4b
1x Card reader
1x Headphone / microphone combo jack (3.5mm)
1x Power connector

Security & Privacy

Security Chip

Firmware TPM 2.0 integrated in SoC

Fingerprint Reader

Lenovo V14 Laptop, AMD Ryzen 3 3250U, 14 Inches FHD, 1TB HDD, 4GB RAM, AMD Radeon Graphics, DOS - Grey 82C600DJAX

Lenovo V14 Laptop, AMD Ryzen 3 3250U, 14 Inches FHD, 1TB HDD, 4GB RAM, AMD Radeon Graphics, DOS - Grey 82C600DJAX

Product Details

Lenovo V14 Laptop, AMD Ryzen 3 3250U, 14 Inches FHD, 1TB HDD, 4GB RAM, AMD Radeon Graphics, DOS - Grey 82C600DJAX

Processor

AMD Ryzen 3 3250U (2C / 4T, 2.6 / 3.5GHz, 1MB L2 / 4MB L3)

Graphics

Integrated AMD Radeon Graphics

Chipset

AMD SoC Platform

Memory

4GB Soldered DDR4-2400

Memory Slots

One memory soldered to systemboard, one DDR4 SO-DIMM slot

Max Memory

Up to 12GB (4GB soldered 8GB SO-DIMM) DDR4-2400

Storage

1TB HDD 5400rpm 2.5"

Storage Support

Up to two drives, 1x 2.5" HDD 1x M.2 SSD 2.5" HDD up to 1TB M.2 2242 SSD up to 512GB M.2 2280 SSD up to 512GB

Card Reader

4-in-1 Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio

Speakers

Stereo speakers, 1.5W x2, Dolby Audio

Camera

0.3MP

Microphone

Mono

Battery

Integrated 35Wh

Max Battery Life

MobileMark 2014: 6 hr (35Wh)

Power Adapter

65W Round Tip (2-pin, Wall-mount)

DESIGN

Display

14" FHD (1920x1080) TN 220nits Anti-glare

Touchscreen

None

Keyboard

Non-backlit, Arabic

Case Color

Iron Grey

Surface Treatment

Texture

Case Material

PC ABS

Dimensions (WxDxH)

327.1 x 241 x 19.9 mm (12.88 x 9.49 x 0.78 inches)

Weight

Starting at 1.6 kg (3.53 lbs)

SOFTWARE

Operating System

FreeDOS

Bundled Software

None

CONNECTIVITY

Ethernet

None

WLAN Bluetooth

11ac, 2x2 BT5.0

Standard Ports

1x USB 2.0

2x USB 3.1 Gen 1

1x HDMI 1.4b

1x Card reader

1x Headphone / microphone combo jack (3.5mm)

1x Power connector

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0

Fingerprint Reader

None

SERVICE

Included Upgrade

None
