Lenovo V15-ADA 82C7007YED Laptop - AMD 3020e, 4 GB RAM, 1TB HDD, Integrated AMD Radeon Graphics, 15.6" HD (1366x768) TN 220nits Anti-glare, Dos Iron Grey
1.Power connector | 5.Power indicator |
2.HDMI 1.4b | 6.NOVO button hole |
3.USB 2.0 | 7.Headphone / microphone combo jack (3.5mm) |
4.2x USB 3.1 Gen 1 | 8.Card reader |
Performance
Processor Family
AMD 3000, AMD Athlon, or AMD Ryzen 3 / 5 Processor
Processor
Processor Name | Cores | Threads | Base Frequency | Max Frequency | Cache | Memory Support | Processor Graphics |
AMD 3020e | 2 | 2 | 1.2GHz | 2.6GHz | 1MB L2 / 4MB L3 | DDR4-2400 | AMD Radeon Graphic |
Operating System
FreeDOS
Graphics
Graphics | Type | Memory | Key Features |
AMD Radeon Graphics | Integrated | Shared | DirectX 12 |
AMD Radeon Vega 8 Graphics | Integrated | Shared | DirectX 12 |
Monitor Support
Monitor Support
Supports up to 2 independent displays (native display and 1 external monitor via HDMI) HDMI supports up to 3840x2160 30Hz
Chipset
Chipset
AMD SoC (System on Chip) platform
Memory
Max Memory[1]
Up to 8GB (8GB SO-DIMM) DDR4-2400
Up to 12GB (4GB soldered 8GB SO-DIMM) DDR4-2400
Memory Slots[2]
One DDR4 SO-DIMM slot
One memory soldered to systemboard, one DDR4 SO-DIMM slot
Memory Type
DDR4-2400
Storage Support
Up to two drives, 1x 2.5" HDD 1x M.2 SSD 2.5" HDD up to 1TB M.2 2242 SSD up to 512GB M.2 2280 SSD up to 512GB
Storage Type
Disk Type | Interface | RPM | Security |
2.5" SATA HDD | SATA 6Gb/s | 5.4K | - |
M.2 2242 SSD | PCIe NVMe, PCIe 3.0 x2 | - | - |
M.2 2280 SSD | PCIe NVMe, PCIe 3.0 x4 | - | - |
Removable Storage
Optical
None
Card Reader
4-in-1 card reader (SD, SDHC, SDXC, MMC)
Multi-Media
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 1.5W x2, Dolby Audio
Microphone
Single microphone
Camera
0.3-megapixel, fixed focus
Battery
Integrated Li-Polymer 30Wh battery
Integrated Li-Polymer 35Wh battery
Max Battery Life[1]
MobileMark 2014: 5 hr (30Wh)
MobileMark 2014: 6 hr (35Wh)
Power Adapter
65W round tip (2-pin, wall-mount) AC adapter, 100-240V, 50-60Hz
Design
Display
Display
Size | Resolution | Touch | Type | Brightness | Surface | Aspect Ratio | Contrast Ratio | Color Gamut | Viewing Angle | Key Features |
15.6" | HD (1366x768) | None | TN | 220 nits | Anti-glare | 16:9 | - | - |
Touchscreen
Non-touch
Input Device
Keyboard
6-row, spill-resistant, multimedia Fn keys, numeric keypad
Keyboard Backlight
Non-backlight
Touchpad
Buttonless Mylar surface multi-touch touchpad
Mechanical[1]
Dimensions (WxDxH)
362.2 x 251.5 x 19.9 mm (14.26 x 9.9 x 0.78 inches)
Weight
Starting at 1.85 kg (4.08 lbs)
Case Color
Iron grey
Surface Treatment
IMR (in-mold decoration by roller)
Texture
Case Material
PC ABS (top), PC ABS (bottom)
Connectivity
NetworkOnboard Ethernet
No Ethernet
WLAN Bluetooth[1]
802.11ac 2x2 Wi-Fi Bluetooth 5.0, M.2 card
Ports[1]
Standard Ports
1x USB 2.0
2x USB 3.1 Gen 1
1x HDMI 1.4b
1x Card reader
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in SoC
Fingerprint Reader
No fingerprint reader
BIOS Security
Power-on password
Supervisor password
Hard disk password
Service
Warranty
Base Warranty
1-year depot service
2-year (1-yr battery) depot service
Environmental
Operating Environment
Temperature[1]
At altitudes up to 2438 m (8,000 ft) - Operating: 5C to 35C (41F to 95F) - Storage: 5C to 43C (41F to 109F)
At altitudes above 2438 m (8,000 ft) - Maximum temperature when operating under the unpressurized condition: 31.3C (88F)
Humidity
Operating: 8% to 95% at wet-bulb temperature 23C (73F)
Storage: 5% to 95% at wet-bulb temperature 27C (81F)
Altitude
Maximum altitude (without pressurization): 3048 m (10,000 ft)
Certifications
Green Certifications
Green Certifications
ErP Lot 3
RoHS compliant
