Name: Monitor Audio C1L In-Ceiling Speakers - EACH
SKU: 686668

Monitor Audio C1L In-Ceiling Speakers - EACH

$ 63.33

$ 253.30

Unavailable

Please select combo product attributes

The combo subtotal is $,SAVE$

This large Tier 1 in-ceiling loudspeaker is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. It has a cut-out dimension of 248 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This large Tier 1 in-ceiling loudspeaker is designed for cost-effective installations, where product simplicity and solid acoustic performance is required. It is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound of the quality youd expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 248 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Optional square grillecan be used with this model.
FEATURES:
- Ideal for cost-effective installations, where product simplicity and solid acoustic performance is required
- Two-way design
- 1 x1.25"(32 mm) C-CAM tweeter with UD Waveguide I for lifelike sound
- 1 x 9" (229 mm) C-CAM mid-bass driver for clear mid-range and full bass
- Patented Quik-Link speaker cable connector for quicker installation(UK patent application no. 2216966.8)
- Tri-Grip II for easy and secure fitment
SPECIFICATIONS:
- System Format:2Way
- Channels:1
- Frequency Response, Installed (-6dB):30 Hz 25 kHz
- Nominal Impedance:8 ohm
- Minimum Impedance (20Hz to 20kHz):6.4 Ohm @ 150 Hz
- Sensitivity (2.83Vrms@1m, Installed):88 dB
- Maximum Peak SPL* (single speaker @ 1m Z-Weighted):116 dB
- Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor):75 W
- Recommended Amplifier Power (RMS into 8 OHM, Music Signal):40 150 W
- Drive Unit Complement:
  - 1 x 9" (229 mm) C-CAM mid-bass driver
  - 1 x 1.25" (32 mm) C-CAM tweeter
- Crossover Frequency:LF/HF: 2 kHz
- Mounting Depth:99 mm (3^7/8")
- Cut-Out Hole Diameter:248 mm (9^3/4")
- External Dimensions (Including Grille (H x W x D)):278 x 278 x 103 mm (10^15/16x10^15/16x4^4/16)"
- Weight (each):2.5 kg (5 lb 8 oz)
- Pre-Construction Bracket:CL-B
- Cabinet Finish:Matt black & Orange
- Sold As:Single Unit
